GIGABYTE Q570M D3H Motherboard – Enterprise-Class Performance and Security
The GIGABYTE Q570M D3H motherboard is designed to meet the needs of enterprise users, providing reliable performance, robust security features, and versatile connectivity. Whether you’re building a business workstation or a secure computing environment, this Micro ATX motherboard offers the features and stability required for demanding applications.
Key Features:
Powerful Processor Support: Compatible with Intel® 10th and 11th Gen Core™ processors, offering excellent performance for multitasking and intensive workloads.
High-Speed Memory: Supports up to 128GB of dual-channel DDR4 memory, with speeds up to 3200 MHz (11th Gen) or 2933 MHz (10th Gen), ensuring smooth operation across all tasks.
Advanced Storage Options: Features dual M.2 slots (PCIe 3.0 x4/x2, SATA) and six SATA 6Gb/s ports, providing flexibility for high-speed SSDs and large storage arrays.
Integrated Graphics: Includes multiple display outputs (HDMI, DisplayPort, D-Sub), supporting up to 4K resolution for crisp, clear visuals.
Enhanced Security: Built-in TPM (Trusted Platform Module) support for hardware-based security, ensuring data integrity and system protection.
Comprehensive Connectivity: Equipped with USB Type-C®, multiple USB 3.2 Gen 1 and USB 2.0 ports, and dual Gigabit Ethernet for fast and reliable network connections.
Durability and Reliability: Constructed with high-quality components, including solid capacitors and reinforced PCIe slots, ensuring long-term stability and performance.
User-Friendly Management: Features like Q-Flash Plus, Smart Backup, and APP Center make system updates and management easy and efficient.
LGA1200 Package:
11th Gen Intel® Core™ i9/i7/i5
10th Gen Intel® Core™ i9/i7/i5/i3, Intel® Pentium®, Intel® Celeron®
Chipset
Intel® Q570 Express Chipset
Memory Support
Dual Channel DDR4, 4 x DIMM slots, up to 128GB, DDR4 2933/2666/2400/2133 MHz (10th Gen), DDR4 3200/3000 MHz (11th Gen)
Onboard Graphics
Integrated Intel® HD Graphics:
1 x D-Sub (1920×1200@60 Hz)
1 x HDMI (4096×2160@30 Hz)
1 x DisplayPort (4096×2304@60 Hz)
Audio
Realtek® ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel
LAN
Dual Realtek® GbE LAN chips (1000/100 Mbit)
Expansion Slots
1 x PCIe x16 slot (PCIe 4.0 for 11th Gen)
1 x PCIe x16 slot (running at x4)
2 x PCIe x1 slots
Storage Interface
2 x M.2 connectors (PCIe 3.0 x4/x2, SATA)
6 x SATA 6Gb/s ports
USB Ports
1 x USB Type-C® (USB 3.2 Gen 1)
4 x USB 3.2 Gen 1 (2 on back panel, 2 via internal header)
6 x USB 2.0/1.1 (4 on back panel, 2 via internal header)
Internal I/O Connectors
1 x 24-pin ATX power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
2 x M.2 connectors
6 x SATA 6Gb/s ports
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x TPM header
1 x serial port header
1 x parallel port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Back Panel Connectors
2 x USB 2.0/1.1
1 x PS/2 keyboard/mouse
1 x D-Sub
1 x HDMI
1 x DisplayPort
1 x USB Type-C® (USB 3.2 Gen 1)
2 x USB 3.2 Gen 1
2 x RJ-45 LAN ports
3 x audio jacks
I/O Controller
iTE® I/O Controller Chip
H/W Monitoring
Voltage, Temperature, Fan speed detection, Fan fail warning, Fan speed control
BIOS
1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Q-Flash Plus, Smart Backup, APP Center (including @BIOS, EasyTune, System Information Viewer)
Bundled Software
Norton® Internet Security (OEM), Realtek® 8118 Gaming LAN Bandwidth Control Utility
Operating System
Windows 10 64-bit
Form Factor
Micro ATX, 24.4cm x 24.4cm
