Product details
Performance Specifications
- # of Cores8
- # of Threads16
- Processor Base Frequency2.90 GHz
- Max Turbo Frequency4.80 GHz
- Cache16 MB Intel® Smart Cache
- Bus Speed8 GT/s
- Intel® Turbo Boost Max Technology 3.0 Frequency ‡4.80 GHz
- Intel® Turbo Boost Technology 2.0 Frequency‡4.70 GHz
- TDP65 W
Memory Specifications
Processor Graphics
- Processor Graphics ‡Intel® UHD Graphics 630
- Graphics Base Frequency350 MHz
- Graphics Max Dynamic Frequency1.20 GHz
- Graphics Video Max Memory64 GB
- 4K SupportYes, at 60Hz
- Max Resolution (HDMI 1.4)‡4096×2160@30Hz
- Max Resolution (DP)‡4096×2304@60Hz
- Max Resolution (eDP – Integrated Flat Panel)‡4096×2304@60Hz
- DirectX* Support12
- OpenGL* Support4.5
- Intel® Quick Sync VideoYes
- Intel® InTru™ 3D TechnologyYes
- Intel® Clear Video HD TechnologyYes
- Intel® Clear Video TechnologyYes
- # of Displays Supported ‡3
- Device ID0x9BC5
Expansion Options
- Scalability1S Only
- PCI Express Revision3.0
- PCI Express Configurations ‡Up to 1×16, 2×8, 1×8+2×4
- Max # of PCI Express Lanes16
Package Specifications
- Sockets SupportedFCLGA1200
- Max CPU Configuration1
- Thermal Solution SpecificationPCG 2015C
- TJUNCTION100°C
- Package Size37.5mm x 37.5mm
